Toshiba SurePOS 500 Series Technical Requirements | |
---|---|
Hardware | Machine Type 4852 |
Product name | SurePOS 500 Model 570 |
Screen | 15" IR Touchscreen |
Processor† | 2.5 GHZ Intel G540 |
Service Processor | Toshiba Light-Path Management |
Maximum Dimensions HxWxD In mm (inches) | 382(15.0)× 359(14.13)×253(9.96) |
Weight | 12.3 kg (27 lbs) |
System Memory‡ | 2 GB DDR3 (8 GB avail)§§ |
Video Memory§ | Up to 256 MB via Intel DVMT driver |
Storage
|
500 GB SATA2 HDD, or 64 GB SSD (2nd) 64 GB SSD (w/SSD only) |
Expansion slots | Express Card slot |
Wireless | Optional wireless dongle cover kit |
Independent Dual Video | Standard |
USB ports | 1× 24v, 1× 12v, 7× USB 2.0 (3× on front tablet) |
RS-232 ports | 3× std, 1× powered, MSR |
RJ45 Ethernet | 1× Gigabit |
Audio Ports/Speaker | Mic-in/line out & headphone, speakers |
Cash Drawer Port | 2 |
System management | Toshiba Remote Management Agent (RMA); SMBIOS; Wake on LAN® (WOL); Pre-Boot Execution Environment (PXE) |
Power management | Deep sleep automation; APM; ACPI |
Operating systems supported** | Microsoft POSReady 2009; Microsoft POSReady 7; Microsoft WEPOS; Windows 7 Pro FES; Windows 7 Ultimate FES; SLEPOS 11 SP3; PC DOS 2000; Windows 8 Pro (YE2014 Tgt); |
Drivers supported | UPOS 1.13.5 or higher |
Optional peripherals | |
PS/2 keyboard/mouse | PS2 Keyboard/Mouse |
Secondary Displays | Toshiba SurePoint™ Solution (touch and non-touch); Integrated 6.5" VGA display; Integrated 2×20 display; Distributed pole mounted 2×20 display; All Points Addressable Character Graphics Display |
Printers | Toshiba SureMark™ single station, dual station, and fiscal printers |
Keyboards | Modular CANPOS keyboards (includes 32 programmable keys) w/optional keylock and pointing device |
Cash drawers | Toshiba full size and compact cash drawer |
Integration trays | Toshiba Retail Integration Tray |
MSR | 3-Track; JUCC |
Fingerprint reader | Biometric fingerprint reader (Toshiba offering provided with HD coating) |
Services | |
Limited warranty†† | One year Depot or On-site service. Multi-year additional service offered. Toshiba International Service* |
Technical support | 24×7 Web Support during warranty period. 24×7 Phone support (check geography availability) |
Service Availability‡‡ | Up to seven years following withdrawal from market |
