Product name | SurePOS 740 | SurePOS 780 |
---|---|---|
Model number | 4900-745, E45, C45 | 4900-785, E85, C85 |
Processor | Intel Celeron T3100 | Intel Celeron G540 or Intel Core i3 2120 |
Hard disk drive* | 500 GB option (standard on E45, C45) | 500 GB option (standard on E85, C85) |
Solid State drive | 64 GB option (upgrade available on E45, C45) | 64 GB option (upgrade available on E85, C85) |
System memory† | 1 GB (2 GB on E45, C45;4 GB max) | 2 GB (8 GB max) |
Video memory | 256 MB (max) (shared with system memory) | |
NVRAM | 128 KB | |
PCI slot | 1 PCI, 1 PCI Express standard | |
Second drive | Field upgrade option 2nd 500 GB HDD or 64 GB SSD installed available on C45 |
Field upgrade option 2nd 500 GB HDD or 64 GB SSD installed available on C85 |
DVD burner | Internal option (standard on C45) | Internal Option (standard on C85) |
Battery backup | Internal UPS (with traditional wide cover only) | |
Toshiba SurePorts | See “Toshiba SurePorts” chart for connectivity options. C45, C85 controller models do not include SurePorts. | |
Front ports | One 12 V USB, one headphone | |
Back ports | 2 PC USB, 4 RS-232, 1 PS/2 keyboard, 1 PS/2 mouse, Audio mic-in, Audio line out, headphone, 1 RJ45 Ethernet 10/100/1000, 2 VGA | |
Systems management | SMBIOS, Wake on LAN, PXE, Wired for Management | |
Power management | Deep sleep automation, ACPI | |
Dimensions (WxDxH) | Low profile Distributed 312 mm × 451 mm 112 mm (107 mm w/o feet; 12.3 × 17.8 × 4.4 in; 4.2” w/o feet) Traditional Narrow: 320 × 475 × 117.3 mm (12.6 × 18.7 × 4.62 in.), Wide 435 × 475 × 117.3 mm (17.4 × 18.7 × 4.62 in.) |
|
Weight | Low profile Distributed 10.2 kg (22.5 lbs) Traditional Narrow: 11.4 kg (25 lbs); Wide: 13.2 kg (29 lbs); Wide with UPS: 19.1 kg (42 lbs) |
|
Power supply | 80 PLUS Gold Efficient Universal Switched Power Supply (47 - 63 Hz), 90 W typical/250 W maximum | |
Operating systems supported§ | Toshiba 4690 OS, V6.3 Enhanced; SUSE Linux Enterprise Point of Service 11, with Service Pack 2 (when available); Microsoft Windows POSReady 2009; Microsoft Windows POSReady 7 (64-bit* and 32-bit), Microsoft Windows 7 Professional (64-bit* and 32-bit), Microsoft Windows 7 Ultimate, SUSE Linux Enterprise 11 Server with Service Pack 2 (when available), SUSE Linux Enterprise 11 Desktop with Service Pack 2 (when available) *32-bit is available preloaded |
|
Drivers supported | UPOS 1.13.3 or higher (includes OPOS, JavaPOS) | |
Applications supported | Toshiba SurePOS ACE; Toshiba General Sales Application; Toshiba 4680 - 4690 Supermarket Application; customized Toshiba applications; Toshiba Business Partner software solutions | |
Management tools | Toshiba Remote Management Agent; IBM Director | |
Limited warranty** | One-year onsite service. Up to two year additional service available | |
Technical support†† | Techline web-based help | |
Service availability | Up to seven years following withdrawal from the market |
SurePorts | ||||
---|---|---|---|---|
Optional top row | Base | Powered USB | RS-485 | RS-232 |
Cash drawer | 2 | |||
Powered USB 2.0 (12 V) | 2 | 5 | ||
Powered USB 2.0 (24 V) | 1 | |||
RS-485 port 5 keyboard | 1 | |||
RS-485 port 4 customer display | 1 | |||
RS-485 port 7 printer‡‡ | 1 | |||
RS-485 port 9 customer display/scanner | 1 | 1 | ||
Powered RS-232 (12 V or 5 V)§§ | 3 (15-pin or 9-pin) |
Peripheral options*** | |
---|---|
Displays | Toshiba SurePoint™ (touch/nontouch), USB, RS-485 and RS-232 40-character and character/graphics displays |
Printers | Toshiba SureMark™ printer, Toshiba 4689-TD5 SurePOS printer, Toshiba Fiscal printers |
Keyboards | USB and PS/2 modular 67-key, ANPOS, and Compact ANPOS; USB and RS-485 50-key |
Cash drawers | Full-size, compact and flip-top |
Integration trays | System unit, table-top, and cash drawer slant top trays |
