Wireless Technology | Bluetooth 2.0 Certified Class 1; Radio Frequency 2.4 GHz; Radio Range (Open Air) 100 m |
Technology | Linear Image |
Ability read | Autodiscriminates all standard 1D codes including GS1 Databar™ linear codes ; Postal Codes: China Post ; Stacked Codes: GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional |
Max Speed | 390 reads/sec |
Durability | IP65. Withstands repeated drops from 2 m |
Interface | Keyboard Wedge, RS 232, USB |
Print contrast | 15% |
Ambient Light | 100,000 lux |
Max Resolution | 0.076 mm (= 3 mils) |
Typical Depth of Field | Printing resolution, contrast and ambient light dependent: 1.5 to 14.0 cm for codes 5 mils; 0.0 to 44.0 cm for codes 7.5 mils; 0.0 to 60.0 cm for codes 10 mils; 0.0 to 80.0 cm for codes 13 mils; 0.0 to 119.0 cm for codes 20 mils; 2.0 to 240.0 cm for codes 40 mils; 5.0 to 300.0 cm for codes 55 mils; 13.0 to 530.0 cm for codes 100 mils; (5 mils = 0.130 mm); |
Reading Indicators | Beeper (Adjustable Tone) ; Datalogic “Green Spot” good read feedback ; Good read LED. |
Battery | Battery Type Lithium-Ion, 2400 mAh; Charge Time 4 Hours; Reads per Charge 22000 |
Applications | The pertiency is user for supermakets, bookstores, shops and industrial manufacture. |
