Technology | Linear Image |
Ability read | Autodiscriminates all standard 1D codes including GS1 Databar™ linear codes ; 2D Codes: Aztec Code, China Han Xin Code, Data Matrix, MaxiCode, QR Code ; Postal Codes: Australian Post, China Post, IMB, Japanese Post, KIX Post, Korea Post, Planet Code, Postnet, Royal Mail Code (RM4SCC) ; Stacked Codes: EAN/JAN Composites, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF, MicroPDF417, PDF417, UPC A/E Composites |
Interface | Keyboard Wedge, RS 232, USB |
Durability | IP52. Withstands repeated drops from 1.8 m |
Print contrast | 25% |
Max resolution | 0.076 mm ( = 3 mils) |
Ambient Light | 0 –100.000 lux |
Typical Depth of Field | Printing resolution, contrast and ambient light dependent: 1High Density (HD): Code 39: 3 mils 2.4 to 9.1 cm / 0.9 to 3.6 in Code 39: 5 mils 0.8 to 11.3 cm / 0.3 to 4.5 in Data Matrix: 5 mils 2.8 to 6.1 cm / 1.1 to 2.4 in EAN-13: 13 mils 1.1 to 17.2 cm / 4.3 to 6.8 in PDF417: 4 mils 1.8 to 6.8 cm / 0.7 to 2.7 in PDF417: 10 mils 0 to 14.3 cm / 0 to 5.6 in QR Code: 6.7 mils 2.1 to 4.2 cm / 0.8 to 1.7 in Standard Range (SR): Code 39: 5 mils 4.0 to 19.0 cm / 1.6 to 7.5 in Code 39: 10 mils 1.0 to 30.0 cm / 0.4 to 11.8 in Data Matrix: 10 mils 2.0 to 16.0 cm / 0.8 to 6.3 in Data Matrix: 15 mils 0 to 23.6 cm /0 to 9.3 in EAN-13: 13 mils 1.5 to 40.0 cm / 0.6 to 15.7 in PDF417: 10 mils 0.5 to 22.0 cm / 0.2 to 8.6 in QR Code: 10 mils 3.0 to 12.5 cm / 1.2 to 4.9 in (5 mils = 0.130 mm); |
Reading Indicators | Beeper (Adjustable Tone); Datalogic ‘Green Spot’ Good Read Feedback ; Good Read LED |
Image Capture | Wide VGA: 752 x 480 pixels; Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2 |
Applications | The pertiency is user for supermakets, bookstores and shops |
