WiFi Power Pack Specifications |
|
DK-USB Power Module |
Designed for DC input 24V with 1A fuse and DC output with rated voltage of 5.0V and rated current of 500mA. Texture surface. USB is short-circuit. |
Wireless Standards |
IEEE 802. 11n, IEEE 802. 11g, IEEE 802. 11b |
Dimensions (WxDxH) |
2.2 x 2.2 x0.7 in. (57 x 57 x 18mm) |
Antenna Type |
On-Board |
Frequency |
2.4- 2.4835GHz |
Single Rate |
11n: Up to 150Mbps (dynamic) 11g: Up to 54Mbps (dynamic) 11b: Up to 11Mbps (dynamic) |
EIRP |
<20dBm (EIRP) |
Reception Sensitivity |
135M: -70dBm@10%PER
65M: -73dBm@10%PER 54M: -76dBm@10%PER |
Wireless Modes |
AP Mode, Router Mode, Client Mode. Repeater Mode, Bridge Mode |
Wireless Functions |
Enable/ Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics |
Wireless Security |
64/128/152-bit WEP,
WPA/ WPA2 WPA-PSK/ WPA2-PSK
|
WAN Type |
Dynamic IP/ Static IP/ PPPoE/ PPTP/ L2TP |
DHCP |
Server. Client, DHCP Client |
Quality of Service |
WMM, Bandwidth Control |
Dynamic DNS |
DynaDna, Comexe, NO-IP |
Auto Power Down Mode |
1-5 Minutes Configurable |
VNP Pass-Through |
PPTP, L2TP, IPSec (ESP Head) |
Access Control |
Local Management Control, Host List, Access Schedule, Rule management |
Firewall Security |
DoS, SPI Firewall IP Address Filter/ MAC Address Filter/ Domain Filter IP and MAC Address Binding |
Management |
Access Control Local Management Remote Manegment |
