Printer type
▪ Multifunction 24-pin flatbed printer
Housing color
▪ Light grey or black
Printing method
▪ Serial, bidirectional logic-seeking
Print head
▪ 24-pin, 2.3 kHz
▪ Noise-optimized arrangement
▪ 500 million dots service life
▪ Easy replacement
Ribbon
▪ Fabric ribbon cartridge, black
▪ Service life in draft characters:
– 10 million (standard)
– 16 million (available separately)
Character matrix hor. x vert.
▪ Letter quality LQ 36 x 24
▪ Draft quality DQ 12 x 24
▪ Very High Speed Draft VHSD 8 x 24
▪ Graphic resolution (dpi) 360 x 180
Printing speed (10 cpi)
▪ VHSD 575 cps
▪ DQ 383 cps
▪ LQ 128 cps
▪ OCR A/B 185 cps
Printing widths
▪ 10 cpi 94 characters
▪ 12 cpi 112 characters
▪ 15 cpi 141 characters
Character pitches Emulation-dependent
▪ 10, 12, 15, 16.6, 17.1, 20 cpi
and proportional font
Line pitches
▪ 6 and 8 lpi, switchable
▪ Additional 1/180 inch increments
Font
▪ VHSD, DQ, LQ (Sans Serif, Roman), OCR A/B, Barcode 39, 2 /5 interleaved
Print attributes
▪ Bold, italics, underlined, elongated print sub/superscript
Character sets
▪ IBM PC2 CP437
▪ ISO 8859-2/-5/-7/-8/-9
▪ Furthers available on CD-ROM
Paper formats
▪ Length 66 - 350 mm
▪ Width 65 - 245 mm
Multiply forms
▪ Original + 6 copies (NCR forms)
