Print stations
1 (receipt)
Printing method
Thermal direct (203 dpi, 8 dots/mm)
Printing columns (max.)
44 standard
56 compressed
Printing speed
350 mm/s monochrome
150 mm/s 2-color
Character density
16.9 cpi standard
20.3 cpi compressed
Paper width
80 mm +0 / - 0.5 mm
57.5 mm + / - 0.5 mm (factory option)
Paper roll diameter
Max. 90 mm
Barcodes
- EAN
- UPC
- Code 39
- Code 128
- Interleaved 2of5
- Codabar
- Code 93
- GS1 DataBar
- PDF417
- QR
- Datamatrix
Sensors
- Paper low
- Paper end
- Cover open
Power supply
24 V DC
Receipt cutter
- Partial cut and full cut
- Reliability 3 million cuts
Codepages
437, 720, 737, 775, 850, 852, 857, 858, 860, 862, 863, 864, 865, 866, 874, 1250, 1251, 1252, 1254, 1255, 1256, 1257, 28591, 28592, 28594, 28596, 28599, 28605
Katakana
Asian Character Sets
- Simplified Chinese
- Traditional Chinese
- Japanese
- Korean
- Thai
Ambient temperature (operation)
5-35 0C (5-90% huminity)
35-50 0C (5-40% huminity)
Noise level
55 dB(A)
Choice of interfaces to the BEETLE or PC
RS232c & USB
PoweredUSB
Interface for cash drawers on the printer
RJ12
Other features
Buzzer
Adapter for 57.5 mm paper (factory option)
Vertical operating
ENERGY STAR® < 0.5 watts in sleep mode (compliant power supply to be used!)
Driver support
Windows 32/64bit
ProBase POS
- JavaPOS
- OPOS-UDM
CUPS (Linux)
Dimensions in mm (HxWxD)
134x145x184
Weight
Approx. 1.3 kg
Driver support
267 cm2
Driver support
Lightgray or black
Services (optional)
Global Deployment Services
– Rollout and installation
Availability Services
– Fast recovery and regular maintenance services
Operational Services
- Remote management and help desk for fast resolutions as well as for user support
