| POS Base | ||||
| Model Name |
CB-100 |
CB-110 |
PB-100 |
PB-110 |
| Mechanism |
Cradle |
Cradle |
POS Base |
POS Base |
|
Charging only |
Full |
Charging only |
Slim |
|
| USB |
x |
2 |
x |
2 |
| COM (DB9) |
x |
x |
x |
x |
|
LAN |
x |
1 |
x |
1 |
| Cash Drawer |
x |
x |
x |
x |
| Power Supply |
DC 5V |
DC 5V |
DC 5V |
DC 5V |
|
Auto Detect |
YES |
YES |
YES |
YES |
| Item | EM-100 |
| Processor | Freescale i.MX 6 1G |
| OS | Android 4.2 |
| Memory | Standard : 1GB |
| Storage | Standard : 8GB |
| Display | 10.1", 1280 x 800, 350nits |
| Touch | Capacitive touch |
| Bluetooth | V4.0+HS |
| WiFi | 802.11 a/b/g/n |
| WWAN(option) | For data, GPRS/EDGE/WCDMA/850/900/1800/1900/2100 |
| GPS(option) | Stand Alone & AGPS (Support Glonass) |
| Rear Camera | 5.0 Mega Pixels, auto focus, flash light |
| Front Camera | 2.0 Mega Pixels |
| Battery | Rechargeable Li-ion battery 3.7V, 8060mAh |
| Working time | 6 hours@film with speaker, 50% brightness, WiFi on |
| Speaker | Internal, 2*0.8W |
| I/O | 1 x SIM (internal ) 1 x Micro SD |
| 1 x DC Jack 1 x Micro HDMI | |
| 1 x Earphone & MIC Jack 2 x Barcode trigger keys | |
| 1 x Micro USB female type 1 x Power button | |
| 1 x POGO Pins (for Cradle), including charging function | |
| LEDs | 1 x red/green LED for power & system status |
| 1 x blue LED for NFC good read | |
| Power Adaptor | Input:100V to 240V AC 50/60Hz 0.8A |
| Output: 5V DC 3A ; AC cable | |
| Dimension | WxLxT: 278mm x 199mm x 20.9mm (without cradle) |
| Temperature | Operation temperature 0 to 40 degrees°C |
| Storage temperature -20 to 60 degrees°C | |
| Humidity | 15% to 80% (no condensation) |
| Sealing | IP65 : W/ MSR / IC CARD /BCR |
| Drop specification | 1M |
| Optional Device Module | 1D barcode scanner (laser) or 2D barcode scanner (image) |
| (Factory Option) | IC card reader ISO7816 or MSR ISO7811-Track 1, 2, 3 , |
| RFID(NFC)13.56MHz, ISO14443 A/B , FeliCa | |
| Certification | CE/FCC/VCCI/BSMI/CCC |
