WIRELESS COMMUNICATIONS |
|
BLUETOOTH WIRELESS TECHNOLOGY |
Protocol: Bluetooth 4.0 Certified Class 2 Radio Frequency: 2.4 GHz Radio Range (Open Air): 25.0 m / 82.0 ft Range distances are measured using the base station. Range with connection to other Bluetooth peripherals may show different results. Security: Data Encryption; Scanner Authentication |
DECODING CAPABILITY |
|
1D / LINEAR CODES |
Auto discriminates all standard 1D codes including GS1 DataBar™ linear codes |
2D CODES |
Aztec Code, Aztec Mesas, Data Matrix, MaxiCode, QR Code, Micro QR Code, China Han Xin Cod |
POSTAL CODES |
Australian Post, British Post, Canadian Post, China Post, Japanese Post, KIX Post, Korea Post, Planet Code, Postnet, Royal Mail Code (RM4SCC) |
STACKED CODES |
EAN/JAN Composites, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF, MicroPDF417, PDF417, UPC A/E Composites |
ELECTRICAL |
|
BATTERY |
Battery Type: Lithium-Ion 700 mAh Charge Time: 2.5 hours when placed in the Base Station or when the Host is powered through the micro USB cable connection Reads per Charge: 3,000 + readings or 5 hours (1 read every 6 seconds) |
INPUT VOLTAGE |
5 VDC +/- 5% |
ENVIRONMENTAL |
|
AMBIENT LIGHT |
0 - 100,000 lux |
DROP RESISTANCE |
Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface |
ESD PROTECTION (AIR DISCHARGE) |
16 kV |
HUMIDITY (NON-CONDENSING) |
5 - 95% |
PARTICULATE AND WATER SEALING |
IP50 |
TEMPERATURE |
Operating: 0 to 50 °C / 32 to 122 °F Storage/Transport: -20 to 70 °C / -4 to 158 °F |
INTERFACES |
INTERFACES USB COM, USB-OEM, USB Keyboard (with BC6020 only) |
|
|
PHYSICAL CHARACTERISTIC |
|
COLORS AVAILABLE |
Light Green/White; Black; Black/Silver |
DIMENSIONS |
11.25 x 4.23 x 2.75 cm / 4.4 x 1.6 x 1.0 in |
ENCLOSURE |
Healthcare model only: Disinfectant-ready enclosure treated with anti-microbial additives (ISO22196 compliant) |
WEIGHT |
With batteries: 85.0 g / 3.0 oz |
READING PERFORMANCE |
|
IMAGE CAPTURE |
Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2; JPEG; JPEG, TIFF |
IMAGER SENSOR |
Wide VGA: 752 x 480 pixels |
LIGHT SOURCE |
Aiming: 650 nm VLD Illumination: White |
MOTION TOLERANCE |
25 IPS |
PRINT CONTRAST RATIO (MINIMUM) |
15% |
READING ANGLE |
Pitch: +/- 65º; Roll (Tilt): up to 360º; Skew (Yaw): +/- 60º |
READING INDICATORS |
Vibration; Beepers, Polyphonic; Datalogic ‘Green Spot’ Good Read Feedback; Product side and upper |
RESOLUTION (MAXIMUM) |
4 mil |
READING RANGES |
|
TYPICAL DEPTH OF FIELD |
5.0 mil : 6.5 to 21.0 cm / 2.6 to 8.2 in 13.0 mil : 5.5 to 39.0 cm / 2.2 to 15.2 in Data Matrix 15.0 mil : 4.0 to 25.0 cm / 1.6 to 9.8 in |
