DECODING CAPABILITY |
|
1D / LINEAR CODES |
Autodiscriminates all standard 1D codes including GS1 DataBar™ linear codes. |
2D CODES |
Aztec Code, Aztec Mesas, Data Matrix, MaxiCode, QR Code, Micro QR Code, China Han Xin Code |
POSTAL CODES |
Australian Post, British Post, Canadian Post, China Post, Japanese Post, KIX Post, Korea Post, Planet Code, Postnet, Royal Mail Code (RM4SCC) |
STACKED CODES |
EAN/JAN Composites, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MacroPDF, MicroPDF417, PDF417, UPC A/EComposites |
ELECTRICAL |
|
AC POWER REQUIREMENTS |
Power Consumption: Operating (Maximum): <500 mA @ 5 V. Operating (Typical): <300 mA @ 5 V. Sleep Mode: < 2.5 mA |
INPUT VOLTAGE |
5 VDC +/- 5% |
ENVIRONMENTAL |
|
AMBIENT LIGHT |
0 - 100,000 lux |
DROP RESISTANCE |
Withstands repeated drops from 1.5 m / 5.0 ft onto a concrete surface. |
ESD PROTECTION (AIR DISCHARGE) |
16 kV |
HUMIDITY (NON-CONDENSING) |
5 - 90% |
PARTICULATE AND WATER SEALING |
IP40 |
TEMPERATURE |
Operating: 0 to 50 °C / 32 to 122 °F. Storage/Transport: -20 to 70 °C / -4 to 158 °F |
INTERFACES |
|
INTERFACES Keyboard |
Wedge / OEM (IBM) USB / RS-232 /USB |
PHYSICAL CHARACTERISTICS |
|
COLORS AVAILABLE |
Black; White. Other colors and custom logo options are available for minimum quantity purchase. |
DIMENSIONS |
15.2 x 15.3 x 6.8 cm / 6.0 x 6.0 x 2.7 in |
TOP CAP DESIGN |
Carbon-Fiber; Silver |
WEIGHT |
150.0 g / 5.3 oz |
READING PERFORMANCE |
|
IMAGE CAPTURE |
Graphic Formats: BMP, JPEG, TIFF; Greyscale: 256, 16, 2 |
IMAGER SENSOR |
Wide VGA: 752 x 480 pixels |
LIGHT SOURCE |
Aiming: 650 nm VLD; Illumination: White |
MOTION TOLERANCE |
25 IPS |
PRINT CONTRAST RATIO (MINIMUM) |
15% |
READING ANGLE |
Pitch: +/- 65°; Roll (Tilt): Up to +/- 360°; Skew (Yaw): +/- 60° |
READING INDICATORS |
Beepers, Polyphonic; Datalogic ‘Green Spot’ Good Read Feedback; Product side and upper illumination; Good Read LED |
RESOLUTION (MAXIMUM) 4 mils |
|
READING RANGES |
|
TYPICAL DEPTH OF FIELD |
Minimum distance determined by symbol length and scan angle. Printing resolution, contrast, and ambient light dependent. |
|
Code 39: 5 mils: 3.5 to 20.0 cm / 1.3 to 7.8 in. EAN-13: 13 mils: 3.0 to 40.0 cm / 1.2 to 15.7 in. Data Matrix: 15 mils: 2.0 to 25.0 cm / 0.8 to 9.8 in |
SAFETY & REGULATORY |
|
AGENCY APPROVALS |
The product meets necessary safety and regulatory approvals for its intended use. The Quick Reference Guide for this product can be referred to for a complete list of certifications. |
ENVIRONMENTAL COMPLIANCE |
Complies to China RoHS; Complies to EU RoHS |
LASER CLASSIFICATION |
Class 2 according to IEC 60825-1 |
LED CLASSIFICATION |
Exempt group according to IEC 62471 |
UTILITIES |
|
DATALOGIC ALADDIN™ Datalogic |
Aladdin configuration program isavailable for download at no charge. |
OPOS / JAVAPOS JavaPOS |
Utilities are available for download at no charge. |
