Printer Specifications
Resolution: 203 dpi/8 dots per mm
Memory: 4 MB Flash supports downloadable programs, receipt formats, fonts and graphics; 64 KB receive buffer
Maximum Print Width: 1.89"/48 mm
Print Length: Max: Continuous
Maximum Print Speed
- Up to 3.5"/90 mm per second (receipt)
- Up to 2.4"/60 mm per second (linerless)
Operating Characteristics
Environmental
- Operating Temperature: 5°F (-15°C) to 122°F (50°C)
- Charging Temperature: 32°F (0°C) to 104°F (40°C)
- Storage Temperature: -22°F (-30°C) to 158°F (70°C)
- Relative Humidity:
- Operation: 10% to 80% non-condensing
- Storage: 10% to 90% non-condensing
- IP Rating: IP54 with protective case
- Drop Spec: 4' (1.2 m) drop to concrete
Agency Approvals
- Emissions: FCC Part 15, Subpart B, EN55022 Class-B, EN55024
- Susceptibility: EN55024, EN61000-4-2, EN61000- 4-3, EN61000-4-4, EN61000-4-5
- Safety: CE, UL, CB
- International marks: CE, FCC, NOM, CCC, RCM, Anatel, BIS, NTC, KCC, BSMI, iDA
Media Characteristics
- Maximum Media Width: 2.28" (58 mm)
- Maximum Media Roll OD Size: 1.18" (30 mm)
- Maximum Media Thickness: 0.10 mm (0.06~0.10 mm)
- Media Types: Direct-thermal receipt paper or linerless paper
Physical Characteristics
- Height 1.48" (37.7 mm)
- Width 3.15" (80.1 mm)
- Length 4.68" (118.8 mm)
- Weight* 0.50 lbs (229 g)
*Weight reflects standard Bluetooth ZQ110 with battery. Optional ZQ110 models (MSR, Wi-Fi) may vary in weight.
Fonts/Graphics/Symbologies
Fonts and Character Sets
- Character size: Font A: 12 x 24; Font B: 9 x 17; Font C: 9 x 24; KOR, CHN: 24 x 24
- Characters per line: Font A: 32, Font B, C: 42; KOR, CHN: 16
- Character sets: Alphanumeric: 95; Expanded Graphics: 128 x 33 page; International: 32
Graphics Supports user-defined fonts and graphics— including custom logos
Barcode Symbologies
- Linear Barcodes: EAN-8, EAN-13, Code39, Code93, Code128, ITF, Coda Bar, UPC-A, UPC-E
- 2-Dimensional: PDF417, Data Matrix, AZTEC, QR Code
Communication and Interface Capabilities
- Bluetooth 3.0 + EDR (standard)
- Security modes 1-4
- Key Bonding
- “Made for iPod/iPhone/iPad” (MFi) certified
- Bluetooth printing from Apple devices
- 802.11b/g/n WLAN (replaces standard Bluetooth); 2.4 GHz
- Wi-Fi Direct, Infrastructure, Ad Hoc
- WEP 64 / 128 bits
- AES, TKIP, AES +TKIP
- WPA1 / WPA2 PSK
- 802.1X WPA1 / WPA2 (EAP-PEAP, EAP-LEAP, EAP-TTLS, EAP-FAST, EAP-TLS)
- Cabled Communications Specifications USB 2.0 Full Speed Interface (12 Mbps)
Optional Features and Accessories
- Linerless printing (with coated silicone platen roller only) is available as a custom solution; please contact Zebra account manager for details.
- The ZQ110 comes with the following accessories in the box:
- AC adapter
- Power cord
- Belt clip
- (1) Standard battery
- (1) Roll of receipt media
- Additional charging and carrying accessories are available for the ZQ110. Please refer to the Accessories Chart on p. 3 for details.
