Media Characteristics
- Media width: 3" (76.2 mm) x 3" (76.2 mm)
- Maximum roll diameter: 1.88"(47.8 mm)
- Core diameter: .4"(10.2 mm) to .75"(19 mm)
- Media thickness: 2 mil(.0508 mm) to 4 mil(0.1016 mm)
- Media types: continuous receipt, continuous, receipt
Operating Characteristics
- Operating temperature: 14° F (-10° C) to 122° F (50° C) Direct thermal
- Storage temperatures: -4° F (-20° C) to 140° F (60° C)
- Operating humidity: 10-90% non-condensing
- Storage humidity: 10-90% non-condensing
- Battery: Li-Ion, 1.5 Ah
Agency approvals
- FCC Part 15 and EN55022 Class B limits
- FCC, ICS, and European Standards for Bluetooth and 802.11b/g
- CSA and IEC 60950 standard for Safety
- NOM
- C-tick
- VCCI
- S-Mark
Physical Characteristics
- Width: 4.11"(104.4 mm)
- Height: 5.34" (135.6 mm)
- Depth: 2.26" (57.4 mm)
- Orientation: Center
Options
- Wireless Bluetooth communication
- Wireless 802.11g communication
- Protective case for increased printer protection
- Shoulder strap
- 4 bay power station
- Vehicle power adapter
- Wireless Security Support (ie. VPN, WPA, WPA2, 802.11i)
Communication and Interface Capabilities
- USB 2.0
- IrDA
- Optional: Bluetooth, 802.11g
Bar Codes/Symbologies
- Linear: Codabar, Code 128, Code 93, Code 39, EAN-8, MSI, Interleaved 2-of-5, Plessey, Postnet, UCC/EAN-128, UPC-A, UPC-E, EAN-18, NW-7, UPC-A and UPC-E with 2 or 5 digit extensions, UPC-A and UPC-E with EAN 2 or 5 digit extensions, FIM
- 2-dimensional: MaxiCode, PDF417, Aztec, QR Code, RSS / GS1 DataBar family (12 barcodes)
Fonts and Graphics
- 25 types, downloadable, scalable fonts
- Supports user-defined fonts and graphics, including custom logos
