Type | Stationary type | Built-in type | ||||
---|---|---|---|---|---|---|
Model | QK30-U | QK31-U | QK31-R | |||
Scanner | Readable codes | 2D code | QR code, micro QR code, SQRC, iQRcode, PDF417, microPDF417, DataMatrix, Aztec, GS1 DataBar Composite(EAN.UCC Composite), MaxiCode | |||
Barcode | EAN-13/-8(JAN-13/-8), UPC-A/-E, UPC/EAN(with add-on), Interleaved 2 of 5(ITF), Standard 2 of 5(STF), CODABAR(NW-7), CODE39, CODE93, CODE128, GS1-128(EAN-128), GS1 DataBar(RSS) | |||||
Minimum resolution | 2D code | 0.25mm | ||||
Barcode | 0.18mm | |||||
Scanning area | 70mm×50mm | |||||
Focusing point | 7mm | |||||
Scan conrmation | LED in three colors: Blue/Red/Green, speaker | - | ||||
Communication interface | Method | USB 1.1-compliant(COM、HID) | RS-232C | |||
Connector | USB connector: type A(with an integrated cable) | USB connector: type B(with a detachable cable) | Mini-DIN connector(with a detachable cable) | |||
Cable length | 1.5m | 1.4m(Sold separately) | 1.5m(Sold separately) | |||
Power | Power | Supply from host device | ||||
Environmental performance | Security level | IPX2 | - | |||
Operating temperature | -5~50°C | |||||
Operating humidity | 10-90% RH (non-condensing/non-freezing) | |||||
Weight | 250g(incl. cable weight) | 170g(excl. cable weight) |
