Pos Wincor Nixdorf BEETLE /Fusion

Code: BEETLE Fusion

Cổng LAN Cổng USB HĐH Window Màn Hình Cảm Ứng

The “all-in-one” POS system and kiosk terminalAll-in-One touch POS and kiosk system with 15” / 18.5" TFT display Energy saving Intel processor technology Various models for different customer requirements for desktop and

Price: Call

The BEETLE /Fusion is a versatile POS terminal and kiosk system

that offers everything these sectors wish for with its elegant “all-in-one” design and graphical user interface. The system dovetails seamlessly into the open standards based BEETLE POS family. It boasts a large choice of standard and retailspecific interfaces. Numerous peripherals tailored to the customer’s requirements can be directly integrated, for example:

Magnetic card reader
Barcode scanner
Customer display
Camera and microphone
Smart card reader
Proximity sensor
Fingerprint reader
Printer/keyboard unit
Waiter lock

Highlights

All-in-One touch POS and kiosk system with 15” / 18.5" TFT display
Resistive, capacitive or IR touch technology
Scalable performance
Integrated peripherals
Smallest footprint
Designed for hospitality
Energy efficient 80PLUS power supply
Flash memory technology (SSD)

Processor	Intel Celeron M 1.0 GHz ULV Intel Celeron M 1.5 GHz Intel Celeron Dual Core T3100 1,9 GHz Intel Core 2 Duo P8400 2.26 GHz
Ram	1GB – 4 GB
Interfaces	RS232 (standard/powered): 1/3 USB (standard/powered): 2/2 Keyboard/mouse: yes Audio: yes Second display: VGA LAN (MBit/s): 10/100/1000 Cash drawer: option eSATA: 1
Display	12.1“ / 15” / 18.5“ TFT Display Capacitive, resistive or infrared touch
System management	Intel Active Management Technology (AMT 4.0) Desktop Management Interface (DMI) Preboot Execution Environment (PXE) Wake on LAN (WoL) Advanced Configuration and Power Interface (ACPI) Management agents (BEETLEINFO)
Dimensions	Wall-mount 12.1“: 320 x 96 x 296 Wall-mount 15“: 370 x 96 x 336 Wall-mount 18.5“: 476 x 81 x 342 Desktop 12.1“: 320 x 265 x 420 Desktop 15“: 370 x 265 x 430 Desktop 18.5“: 476 x 265 x 434
Operating Systems	Windows XP Professional Windows POSReady 2009 Windows 7 (in preparation) WNLPOS (Linux)
