POS Machine Wincor Nixdorf BEETLE /SX

Code: BEETLE SX

Cổng LAN Cổng USB HĐH Window

The Wincor Beetle SX is distributed system with modular components with a Intel Celeron M 1.0 processor

Price: Call

Wincor BEETLE /SX Modular mini POS system with

a Designed for lowest total cost of ownership (TCO)
Retail-hardened system design for maximum reliability
Optimally geared to the future due to an open system architecture
System availability over several years
Attractive design with a small footprint allowing countertop and undercounter installations
Management readiness due to integrated system management functionality
User- and customer- display adaptablesealed housing

Highlights

Sealed system box – dust-tight aluminum housing prevents soiling of the system interior
Ultra-low-voltage processor technology – the processor's ultra-low power consumption ensures that the system does not generate much heat and reduces power costs
Innovative storage technology – uDOC (USB Disk on Chip) is a solid-state flash memory that delivers maximum availability data security and has a long life.
Expandable to meet custom requirements – great variety of proven PC and POS-specific interface extensions internally and externally via an I/O hub.
Low-cost service concepts – the modular design consisting of system box, external power supply unit and expandable I/O hub forms the basis for low-cost swap service concepts.

Processor	Intel Celeron M ULV 1.0 Ghz, 512 KB SLC
Ram	256 MB – 2 GB
I/O Expansion slots	1 x PCI (option) 1 x PCI express (option)
Interfaces	RS232 (standard/powered): 1/1 - 7 USB (standard/powered): 3/0 - 3 Keyboard/mouse: Yes Audio: Yes VGA: Optional Digital video: Optional LAN onboard: Yes
Drivers	HDD (option)DVD (option)2 x Solid State Drive (SSD)
Power supply unit interfaces	Cash drawer: Yes 24 V for POS printer: YesRubber connector: Yes
I/O HUB Interfaces	PoweredUSB: 6Powered RS232: 4 (option)
System management	Wired for Management (WfM) Desktop Management Interface (DMI) Preboot Execution Environment (PXE) Wake on LAN (WoL) Advanced Power Management (APM) Advanced Configuration and Power Interface (ACPI) BEETLEVIEW
Dimensions	(W x D x h) in mm: 288 x 286 x 103
Operating Systems	Windows Embedded for Piont of Service (WEPOS)Windows XP ProfessionalWNLPOS (Linux)
Options	External I/O hub
